Battery
Alfen คือหนึ่งในผู้ผลิตแบตเตอรี่อุตสากรรมจากประเทศเนเธอร์แลนด์ ซึ่งมีเทคโนโลยีอันทันสมัย สามารถใช้งาน
ร่วมกับพลังงานลม พลังงานแสงอาทิตย์ ได้เป็นอย่างดี
มีความจุตั้งแต่ 130 kWh – 2MWh มีการรับประกัน 2 ปี
Play Video
Battery
The Battery at a glance
TheBattery balances energy supply and demand, avoiding significant investments in power grids and connections. In addition, TheBattery enables trading opportunities as well as autonomous electricity grids in combination with solar and/or wind energy. TheBattery is being used by multiple utilities, grid operators, large and small energy producers and traders, EV fast charging service providers and industrial production companies
The Battery applications
TheBattery can be used in several applications. TheBattery enables trading opportunities while balancing energy supply and demand in combination with renewable energy sources. TheBattery avoids significant investments in power grids and connections absorbing fluctuations in peak demands. Also TheBattery can enable autonomous electricity grids in combination with solar and/or wind energy.
The Battery Specifications
Alfen offers a wide range of modular energy storage systems suitable for every application, whether the functionality is e-trading, creating an off grid power supply or enabling peak shaving.
Standard general features
| Energy Management: | Alfen EMS |
| Supported applications: | Frequency Response, Peakshaving, Blackstart, Offgrid |
| Grid voltage: | 3p 400 Vac (no neutral), with microgrid option: 3p 230/400 Vac (with neutral), |
| other voltages upon request | |
| Grid frequency: | 50 Hz, other frequencies upon request |
| Ambient temperature range: | -20˚C – 40˚C |
| Battery efficiency: | 98,6% |
| Inverter efficiency: | 97,0% |
| Local control: | PLC based control with touch screen |
| Modularity: | Stackable units |
| Warranty: | 10 year performance warranty on battery (conditions available upon request), |
| rest of system 2 year on components | |
| Remote service: | Back office via communication gateway |
| Climatization: | Air-conditioned battery compartment, air-cooled power converter compartment |
| Container size per unit: | 10ft, 20ft, 40ft |
Standard stackable features
| Type | battery capacity (kWh) | Usable capacity (kWh) | Power | Power | container type (ft) | System Weight (kg) | Off-grid option available |
| kVA | kVA | ||||||
| (25 C) | (40 C) | ||||||
| TB-137-1C | 137 | 130 | 180 | 141 | 10 | 4400 | No |
| TB-274-1C | 274 | 260 | 318 | 249 | 20 | 7200 | Yes |
| TB-548-1C | 548 | 521 | 636 | 498 | 20 | 10200 | Yes |
| TB-891-1C | 891 | 846 | 1272 | 995 | 40 | 16100 | Yes |
| TB-1096-1C | 1096 | 1041 | 1272 | 995 | 40 | 17900 | Yes |
| TB-1507-1C | 1507 | 1432 | 1908 | 1493 | 40 | 22700 | Yes |
| TB-2055-1C | 2055 | 1952 | 2544 | 1991 | 40 | 28700 | No |
เลื่อนซ้าย-ขวาเพื่อดูตาราง
